PNCTF, PNCTFK, Rubber Insulated Sheathed Flexible Power Cables

Japan PSE certified PNCTF and PNCTFK rubber insulated sheathed flexible cables, manufactured to JIS C 3301 standards. Rated 300V at 60°C, available in 2-core, 3-core and 4-core configurations with conductor sizes from 0.75mm² to 5.5mm². These rubber cables offer excellent flexibility, weather resistance, heat resistance and durable performance for demanding Japanese market applications. Ideal for power tools, industrial equipment, construction sites, outdoor equipment and portable machinery. PSE certified with RoHS and REACH compliant materials, customizable lengths available.

No.of Core:2 Cores, 3 Cores, 4 Cores

Electrical Voltage:300V

Temperature:60°C

Approvals:PSE Certified

Power Cable Standards :JIS C 3301

Our PNCTF, PNCTFK Power Cable products are fully molded with a low profile ergonomic design and RoHS, REACH and PAHS compliant.

Certainly! If you're looking for PNCTF, PNCTFK, We are your best choice.

Categories: Japan PSE Rubber Power Cables

PNCTF, PNCTFK Available Cord / Cables Wire Styles

Cord Type	Gauge/Sq.mm
PNCTF, PNCTFK	2x0.75mm², 2x1.25mm², 2x2.00mm²
	3x0.75mm², 3x1.25mm², 3x2.00mm²
	4x0.75mm², 4x1.25mm², 4x2.00mm²

This cable can also be supplied in other lengths, colors and jacket compounds. See how to customize a power cord.

Product Description of PNCTF, PNCTFK


Number of Poles and Wires:	2 Cores, 3 Cores, 4 Cores
Power Cables Standard:	JIS C 3301
Rated Voltage:	300V
Rated Temperature:	60°C
Certified:	PSE
Copper Conductor Material:	Oxygen free Copper (OFCU)
Outer Jacket Material:	Rubber
Core Structure:	Cores twisted together
Flamability Rating:	UL 94V-0
Color	Black / White are standards, but any color available customized
Environmental Certifications:	RoHS, Reach, PAHs
Country of Origin:	Made In China
Packing:	Standard Export Carton

Specifications of Japan PSE Rubber Power Cables:

PNCTF, PNCTFK Wire Styles, Rubber Insulated Sheathed Flexible Power Cables

Japan PSE Rubber Power Cables

More details of PNCTF, PNCTFK for reference:

PNCTF, PNCTFK of Japan PSE Rubber Power Cables

Frequently Asked Questions

Common questions about this flexible power cable

PNCTF is a rubber insulated sheathed flexible cable built to JIS C 3301, rated 300V, available in 2 cores, 3 cores, 4 cores with conductors of 0.75mm², 1.25mm², 2.0mm², 3.5mm², 5.5mm². It is used for Japanese appliances, tools and equipment internal/external wiring.

It is manufactured to JIS C 3301 and supplied with PSE certification; the relevant harmonised/regional designation and test reports are available. Confirm the exact approval (e.g. UL, VDE, PSE or SAA) for the destination market.

Conductor sizes are 0.75mm², 1.25mm², 2.0mm², 3.5mm², 5.5mm², in 2 cores, 3 cores, 4 cores. Larger cross-section reduces voltage drop and heating on longer or higher-current runs.

Rubber (e.g. EPR/elastomer, H07RN-F/SOOW types) stays flexible in the cold, resists oil, abrasion and weather, and suits outdoor, industrial and site use; PVC is smoother and lower cost for indoor appliances. Use the water-resistant grade for pumps and wet locations.
