VSF, PVC Insulated Single Flexible Power Cords

Japan PSE certified VSF PVC insulated single core flexible cables, manufactured to JIS C 3306 standards for Japanese electrical applications. Rated 300V at 60°C, available in conductor sizes from 0.5mm² to 2.0mm² with excellent flexibility and flame retardant performance. Ideal for internal wiring of home appliances, lighting fixtures, office equipment and small electrical devices. PSE certified with RoHS and REACH compliant materials, customizable lengths and jacket colors available.

No.of Core:1 Core

Electrical Voltage:300V

Temperature:60°C

Approvals:PSE Certified

Power Cable Standards :JIS C 3306

Our VSF Power Cable products are fully molded with a low profile ergonomic design and RoHS, REACH and PAHS compliant.

Certainly! If you're looking for VSF, We are your best choice.

Categories: Japan PSE PVC Power Cables

VSF Available Cord / Cables Wire Styles

Cord Type	Gauge/Sq.mm
VSF	1x0.5mm², 1x0.75mm², 1x1.25mm², 1x2.0mm²

This cable can also be supplied in other lengths, colors and jacket compounds. See how to customize a power cord.

Product Description of VSF


Number of Poles and Wires:	1 Core
Power Cables Standard:	JIS C 3306
Rated Voltage:	300V
Rated Temperature:	60°C
Certified:	PSE
Copper Conductor Material:	Oxygen free Copper (OFCU)
Outer Jacket Material:	PVC
Core Structure:	Cores twisted together
Flamability Rating:	UL 94V-0
Color	Black / White are standards, but any color available customized
Environmental Certifications:	RoHS, Reach, PAHs
Country of Origin:	Made In China
Packing:	Standard Export Carton

Specifications of Japan PSE PVC Power Cables:

VSF Wire Styles, PVC Insulated Single Flexible Power Cords

Japan PSE PVC Power Cables

More details of VSF for reference:

VSF of Japan PSE PVC Power Cables

Frequently Asked Questions

Common questions about this flexible power cable

VSF is a single core flexible cable built to JIS C 3306, rated 300V, available in 1 core with conductors of 0.5mm², 0.75mm², 1.25mm², 2.0mm². It is used for Japanese appliances, tools and equipment internal/external wiring.

It is manufactured to JIS C 3306 and supplied with PSE certification; the relevant harmonised/regional designation and test reports are available. Confirm the exact approval (e.g. UL, VDE, PSE or SAA) for the destination market.

Conductor sizes are 0.5mm², 0.75mm², 1.25mm², 2.0mm², in 1 core. Larger cross-section reduces voltage drop and heating on longer or higher-current runs.

Yes. It can be supplied cut and stripped, with tinned ends or terminals, or as a finished cord set with plugs and IEC/NEMA connectors to order, in the required colour and packaging.
