NEMA L14-30P to NEMA L14-30R X2 for RV Generator Power Adapter Cord Sets

30A to 30A 125V/250V for RV Generator Power Adapter Cord Sets

4 Prong to 4 Prong

NEMA L14-30P to NEMA L14-30R X2 Power Adapter Cord Sets, RV Adapter Cord Sets, 30A NEMA L14-30P to 30A NEMA L14-30R X2, Twist Locking Plug, 125V/250V, with Y Splitter, use for EV Power Cables, Generator Adapter Cord Sets, Yacht Shore Power Adapter Cord Sets: with UL cUL, ETL Certified, NEMA L14-30P Male Plug to NEMA L14-30R X2 Female Receptacle Easy Unplug Design for RV Power Cords, EV, Trailer, Camper, Yacht Shore Power Adapter Cord Sets and Generator Adapter Cord Sets.

Male Plug:30A NEMA L14-30P Male plug

Female Connector:30A NEMA L14-30R X2 Female Receptacle

Voltage :125V/250V

Approvals :UL/cUL/ETL Certified

Plug / Connector / Wires: Any Color Available

Cable Length: 1FT, 1.5FT, 2FT, 3FT, 10FT, 25FT, 50FT, 75FT, 100FT, And Any Length Available

Certainly! If you're looking for NEMA L14-30P to NEMA L14-30R X2 Power Adapter Cord Sets, We are your best choice.

Categories: RV Generator Power Adapter Cord Sets, RV Generator Power Extension Cords

NEMA L14-30P to NEMA L14-30R X2 for RV Generator Power Adapter Cord Sets Product Description


Plug / Connector Standard:	NEMA L14-30P to NEMA L14-30R X2
Maximum Current rating:	30A to 30A
Maximum Voltage:	125V/250V
Number of Poles and Wires:	4 prong to 4 prong
Copper Conductor Material:	Oxygen free Copper (OFCU)
Outer Jacket Material:	PVC, Rubber, Halogen-Free, Textile braid
Blade Material:	Nickel Coated Brass
Flamability Rating:	UL 94V-0
Color	Black / White are standards, but any color available customized
Environmental Certifications:	RoHS, Reach, PAHs
Testing:	Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity
Country of Origin:	Made In China
Packing:	Standard Export Carton

More pictures of Power Adapter Cord Sets for reference:

NEMA L14-30P to NEMA L14-30R X2 Power Adapter Cord Sets

Packaging Method For RV Generator Power Adapter Cord Sets

Power Adapter Cord Sets Packaging with Export Cartons, Pallets, FCL or LCL, Container by Sea or Air.

Frequently Asked Questions

Common questions about this RV, generator and shore-power cord

This adapter cord converts a NEMA L14-30P source connection to a NEMA L14-30R equipment/inlet connection, rated 125V/250V, so RVs, campers and portable generators can be powered from a pedestal, generator or outlet that uses a different NEMA configuration.

No. The NEMA L14-30P to NEMA L14-30R adapter cord carries power through unchanged: it does not convert voltage and does not increase current. The load is limited by the lowest-rated connector and the supply circuit, so a 30 A adapter on a 50 A supply still delivers only what the 30 A side and the RV can safely draw.

The NEMA L14-30P end (male 'P') plugs into the pedestal, generator or wall outlet; the NEMA L14-30R side is the female 'R' end that feeds the equipment, here split into multiple tails so several devices/inlets can share one source. Do not exceed the rated current of the smallest connector.

Yes. Cord length and conductor gauge for the NEMA L14-30P to NEMA L14-30R adapter cord are built to order (heavier gauge for longer runs to limit voltage drop), with the exact NEMA plug and receptacle combination and strain relief specified for RVs, campers and portable generators.
