What is a NEMA 6-20P power cord with stripped free ends?

The NEMA 6-20P is a North American male plug rated 20A 250V, used for 250 V tools, compressors, welders and commercial equipment; the free end is supplied with the outer jacket removed and the conductors stripped and prepared for direct wiring into equipment or a terminal block. It is UL/cUL (and where marked ETL) listed with RoHS/REACH/PAHS/Prop 65-compliant cable.

What does 'outer jacket removed' (bare leads) mean on this cord?

The free end is supplied with the outer jacket stripped and the conductors prepared (tinned, or with terminals on request) so the cord can be wired directly into equipment or a terminal block rather than ending in a plug.

What does the NEMA 6-20P mate with, and which devices use it?

A NEMA 6-20P mates with the matching NEMA 6-20R of the same rating. It is typically used for 250 V tools, compressors, welders and commercial equipment; always match the amperage and voltage to the equipment and circuit.

Is the NEMA 6-20P grounded?

Yes, the NEMA 6-20P includes an earthing/grounding pin and must be used with a matching grounded outlet; do not remove or bypass the ground pin.

American Power Cord NEMA 6-20P Right Angle Male Plug, 20A 250V 3 prong 2 poles 3 wires, UL/ETL/cULus Certified

NEMA 6-20P plug | Right angle bent model | 20A 250V heavy-duty grounded plug

American power cord NEMA 6-20P Right Angle Male Plug is rated for 20A 250V.
This American AC cord is manufactured in accordance with NEMA 6-20P standards and holds UL, ETL and cULus certifications.
It features a non-rewirable 3 prong 2 poles 3 wires molded plug With Earthing Contact (Grounded), permanently bonded to a flexible non-rewirable cord.
For general applications, this American power cord Right Angle supports two flexible cable options for the North American and Canadian markets: flexible cables with thermoplastic PVC insulation, and flexible cables with crosslinked elastomeric rubber insulation.
Both the power plug and cable are made of eco-friendly materials and are fully compliant with RoHS, REACH, PAHs and Prop 65 requirements. The American cords support fully customizable lengths, standard black/white finishes and custom Pantone colors. All NEMA 6-20P American power cords are widely applied to small home appliances and consumer electronics.

Electrical Rating:20A

Voltage:250V

Plug / Connector:NEMA 6-20P

Number of Poles and Wires:3 prong 2 poles 3 wires

Approvels:UL/ETL/cULus Certified

Samples:Available
Batch lead time:15-20workdays
MOQ:200 - 1000 Pieces
Production capacity:2 million pieces per month
Currency:Export business supports settlement in RMB, USD, EUR and GBP etc.
Export rights:We are a China-based factory with our own export license.

The basic standard used to investigate products in this category is UL 817, "Cord Sets and Power-Supply Cords." (CSA C22.2 No. 21 for Canada) Molded-on IEC-configuration fittings are additionally investigated to the applicable requirements of UL 60320-1 (CSA C22.2 No. 60320-1 for Canada), "Appliance Couplers for Household and Similar General Purposes - Part 1: General Requirements."

Categories: American UL Power Cords

American Power Cord NEMA 6-20P Right Angle Male Plug, 20A 250V Product Description


Plug / Connector Standard:	NEMA 6-20P UL 817, CAN/CSA C22.2 No. 21
Approvals:	UL/ETL/cULus Certifications
Maximum Current rating:	20A
Maximum Voltage:	250V
Number of Poles and Wires:	3 prong 2 poles 3 wires
Indoor/Outdoor:	Both Available
Copper Conductor Material:	Oxygen free Copper (OFCU)
Outer Jacket Material:	PVC, Rubber, Halogen-Free, Textile braid
Blade Material:	Nickel Coated Brass
Flamability Rating:	UL 94V-0
Color	Black / White are standards, but any color available customized
Environmental Certifications:	RoHS, Reach, PAHs, Prop 65
Testing:	Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity
Country of Origin:	Made In China
Packing:	Standard Export Carton, Pallets

American Power Cord NEMA 6-20P Right Angle Male Plug, 20A 250V Available Cord / Cables Wire Styles

Gauge/ # Conductors	Cord Type
3Cx18AWG, 3Cx16AWG	SPT-2, SPT-3
3Cx18AWG, 3Cx16AWG	HPN
3Cx18AWG	SVT, SVTO, SVTOO
3Cx18AWG, 3Cx16AWG, 3Cx14AWG, 3CX12AWG	SPT-3, SJT, SJTO, SJTW, SJTOO, SJTOW, SJTOOW
