Europe Power Cords, Perilex 5 Pins Three Phase Cooker Plug, 16A 230/400V, VDE, TUV, CE Certified

Type: Perilex

Europe Power Cords, Perilex 5 Pins Three Phase Cooker Plug, 16A 230/400V, VDE, TUV, CE Certified

Europe Perilex Power Cords, 16A 230/400V, 5 Pins Three Phase Plug. The Europe three-phase cords according to DIN 49446 Perilex standards with VDE, TUV certification. 5 poles (3 phase + neutral + earth) moulded with flexible cords, built for electric cookers, stoves and ovens. These five-pin power cords match flexible cables with thermoplastic PVC insulation (H05VV-F) and crosslinked elastomeric rubber insulation (H05RN-F, H07RN-F) in the Europe market. Fully moulded ergonomic design, RoHS and REACH compliant.

Plug Type :Perilex

Approvels :VDE, TUV, CE Certified

Electrical Rating :16A

Voltage :230/400V

Plug / Connector Standards :DIN 49446

Europe VDE, TUV, CE 5 pins Perilex plug, Europe Power Supply Cords with VDE, TUV, CE Certified List.
Built to DIN 49446 standards.
Rated up to 16A 230/400V.

Categories: European VDE Power Cords

Europe Power Cords, Perilex 5 Pins Three Phase Cooker Plug, 16A 230/400V, VDE, TUV, CE Certified Product Description


Plug / Connector Standard:	DIN 49446
Maximum Current rating:	16A
Maximum Voltage:	230/400V
Number of Poles and Wires:	5 poles, 5 wires
Copper Conductor Material:	Oxygen free Copper (OFCU)
Outer Jacket Material:	PVC, Rubber, Halogen-Free, Textile braid
Blade Material:	Nickel Coated Brass
Flamability Rating:	UL 94V-0
Color	Black / White are standards, but any color available customized
Environmental Certifications:	RoHS, Reach, PAHs
Testing:	Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity
Country of Origin:	Made In China
Packing:	Standard Export Carton

Europe Power Cords, Perilex 5 Pins Three Phase Cooker Plug, 16A 230/400V, VDE, TUV, CE Certified Available Cord / Cables Wire Styles

Gauge/ # Conductors	Cord Type
5x0.75mm²	H05VV-F, H05RR-F, H05RN-F
5x1.0mm²	H05VV-F, H05RR-F, H05RN-F
5x1.5mm²	H05VV-F, H05RR-F, H05RN-F, H07RN-F
5x2.5mm²	H05VV-F, H05RR-F, H05RN-F, H07RN-F

Lengths, jacket colors and plug types are all made to order. See how to customize a power cord.

Power Cords Terminals Processing Available Opposite End

We finish the opposite end of a power cord to suit the equipment it goes into, stripping the cable back and fitting terminals, strain relief or a connector.
If you are not sure which finish you need, see power cord wire end options.

Remove Outer Jacket

Remove Outer Jacket
Semi-Strip

Remove Outer Jacket
Tooth Terminals

Remove Outer Jacket
Tinned

Cable Clamp
Strain Relief

Remove Outer Jacket
Terminals / Sleeve

Remove Outer Jacket
Round Ring Terminals

Remove Outer Jacket
Connector

Europe Power Cords, Perilex 5 Pins Three Phase Cooker Plug, 16A 230/400V, VDE, TUV, CE Certified, also to IEC C5, IEC C13, IEC C14, IEC C15, IEC C19, IEC C20 etc Cord sets connector. All European VDE Power Cords can be paired with various IEC 60320 Connectors according to customer requirements.

Lamp Sockets: E12, E14, E26, E27, Hooks, etc for IRAM 2073 Plug, Argentina Power Supply Cords

Packaging Method For Power Cords

European VDE Power Cords Packaging with Export Cartons, Pallets, FCL or LCL, Container by Sea or Air.

Frequently Asked Questions

Common questions about this international power cord

This cord has a moulded Perilex rated 16A 230/400V on a 3-wire (live, neutral, earth) cable. The equipment end is supplied with the jacket removed and all conductors stripped, ready to wire into the appliance or terminal block. It is certified to VDE, TUV, CE.

The finished cord set is certified to VDE, TUV, CE for the target market; test reports and the certificate are available on request, and the cable uses RoHS-, REACH- and PAHS-compliant materials.

On the Europe Power Cords Perilex 5 Pins Three Phase Cooker Plug 16A 230/400V, connect live and neutral to the corresponding terminals and the green/yellow conductor to the protective-earth terminal, then secure the strain relief. Ends can be supplied tinned or pre-fitted with terminals.

On the Europe Power Cords Perilex 5 Pins Three Phase Cooker Plug 16A 230/400V, the 2-wire version has no earth and suits double-insulated Class II appliances; the 3-wire version adds a protective-earth conductor for grounded Class I equipment. Choose the version matching the appliance class and inlet.

EN 50075 is the national standard the cord is manufactured and tested against; it defines the plug dimensions, pin layout and safety requirements for the target market. The certified cord carries the VDE, TUV, CE approval and is supplied to that standard.

Yes. We strip the cable back to length, fit terminals or a connector, and size the strain relief to the equipment. Each finish is described in power cord wire end options.
