What is an IEC C18 appliance inlet?

The C18 is the 2-pole, unearthed male appliance inlet rated 10 A at 250 V and 70 C that receives a C17 connector. It is the ungrounded counterpart of the C14 inlet and is fitted to double-insulated (Class II) power tools, motors and appliances rated up to 10 A that have no protective-earth terminal.

How is a C18 inlet different from a C14 inlet?

Both share the 10 A IEC sheet size, but the C14 is a three-pole earthed inlet whereas the C18 has only line and neutral contacts with no earth pin. A C18 is used exclusively on Class II equipment; earthed devices use C14, and the two should not be interchanged across safety classes.

Which cord connector mates with a C18 inlet?

The C17 female cord connector is the designated mate for a C18 inlet. A C13 may physically fit in some cases, but the certified pairing is C17-to-C18 for an unearthed 10 A circuit, and using the correct coupler preserves the equipment's safety approval.

Is a C18 inlet available as a panel-mount or rewireable part?

Yes. C18 inlets are produced as snap-in or screw panel-mount connectors with quick-connect or screw terminals, and as rewireable inline connectors, for manufacturers building Class II tools and appliances. Select the terminal style and confirm the 10 A/250 V, 70 C rating for the application.

Do you supply C18 inlets and matched C17 cords?

Yes. We provide panel-mount and rewireable C18 inlets together with matched C17 cord sets, using flexible durable cable and regional wall plugs under UL/cUL, ETL or VDE certification. Custom terminals, colors and lengths are available at an MOQ of 200-1000 pieces.

IEC 60320 C18 Power Cords & Custom Connectors – Straight, Angled, Locking

IEC 60320 Diagram

IEC 60320 C18 power cords and connectors in straight, right-angle, and locking designs. Custom OEM/ODM available for printers, audio equipment, projectors, and lighting fixtures. These IEC 60320 C18 connectors are 10A rated, non-grounded, and tailored to your exact specs.

IEC Power Cords, IEC 60320 C18 Connector Plug, Type C18, 2 poles, 2 wires, UL, ETL, VDE, TUV, SAA, KC, PSE Certified

Amperage:

10A, 13A, 15A

Voltage:

125V/250V

Plug:

IEC 60320 C18

For IEC 60320 C18 Power Cords Connector and other specs not shown above, send the drawing or part number through the contact page and we will reply with price and lead time.

Need the same cord in a different length, plug, cable or color, or with a different wire end? See how to customize a power cord and power cord wire end options.

Power Cords Supplier, Manufacturer In China

IEC 60320 C18 Power Cords & Custom Connectors – Straight, Angled, Locking

IEC 60320 C18 Power Cords Connector

IEC Power Cords, IEC 60320 C18 Connector Plug, Type C18, 2 poles, 2 wires, UL, ETL, VDE, TUV, SAA, KC, PSE Certified

Plug:
