IEC 60320 C22 Power Cords Connector

- IEC 60320 Standards C22 Connector International Power Cords
IEC 60320 C22 power cords and connectors in straight, right-angle, and locking designs. Custom OEM/ODM available for servers, PDUs, data centers, and industrial heating equipment. These IEC 60320 C22 connectors are 16A/20A rated with 120°C high-temperature resistance and tailored to your exact specs.
For IEC 60320 C22 Power Cords Connector and other specs not shown above, send the drawing or part number through the contact page and we will reply with price and lead time.
Need the same cord in a different length, plug, cable or color, or with a different wire end? See how to customize a power cord and power cord wire end options.
Contact with Power Cords

Have any Question?

Power Cord & Power Connectors Manufacturer With RoHS, Reach, PAHs Compliant.

Frequently Asked Questions

Common questions about IEC 60320 C22 Power Cords Connector

The C22 is the high-temperature, 3-pole earthed male appliance inlet in the 16 A IEC 60320 sheet that receives a C21 connector. It is the hot-condition equivalent of the C20 inlet, built with heat-resistant materials and extra keying for high-current equipment that runs hot.

The C20 is the standard 16 A inlet rated around 70 C, while the C22 is rated for a hot condition near 150 C and carries additional keyways so only a C21 connector fits. The two look similar in size but are not interchangeable where high temperature is involved.

The C21 female cord connector is the designated mate for a C22 inlet. A standard C19 is blocked by the extra keyway, which deliberately enforces use of the heat-rated C21 cord on equipment that could otherwise overheat an ordinary coupler.

C22 inlets appear on high-power heating and industrial equipment, certain stage-lighting and entertainment power systems, and specialized machinery requiring both 16 A current and a 150 C-class coupler. It is uncommon in ordinary IT equipment, which normally uses C20.

Yes. We can provide panel-mount or inline C22 inlets and matched heat-rated C21 cord sets with suitable high-temperature cable, regional wall plugs and certification. Send the inlet specification; MOQ is 200-1000 pieces, samples in 7-15 days and 15-20 working days for production.
